CIP tank

Stirring, process and storage tanks for cleaning and CIP processes

Our CIP tanks are used for the provision and storage of purified water and cleaning agents in sizes ranging from 400 l to 5,000 l. These stainless steel pressurised tanks with heating and insulation, equipped with spray balls for reproducible CIP cleaning are used in the pharmaceutical industry and by equipment manufacturers for high-purity media.
CIP -11

Articles in the range CIP tank

cip2
Biotechnology Cosmetics industry

CIP tanks with insulating material

Pharmaceutical mixing and process tank for CIP liquids pursuant to PED 2014/68/EU based on module G.
Upper section with folding dome pressure cover and welded conical nozzle. Torispherical base design.

The tank is equipped with a heating/cooling jacket and insulation cover.

Equipment also includes:
  • Magnetic stirrer as a bottom agitator for a viscosity of 100 mPas
  • Metaglas sight glass
  • LED sight glass lights
  • Rupture disc / safety valve
  • Product tubes
  • CIP cleaning nozzle
AREA OF APPLICATION:
Industry: pharmaceutical, food industry
Product: Cleaning liquids, demineralised water
SIZE:
500 l – 4.000 l
OPERATING DATA:
Tank product chamber:
p = -1 / +3 bar,
t = -10 / +150 °C
Double wall:
p = -1 / +3,5 bar,
t = -10 / +150 °C
MATERIAL:
Parts in contact with product 1.4404/ 1.4435/ 316L , with APZ 3.1 AD 2000, Ra <0.5µm
